Concrete Padstone 440 × 215 × 215mm

Precast concrete padstone sized 440 × 215 × 215mm, supplied for use where a bearing pad is specified to help distribute concentrated loads into masonry at support details.
This format is commonly selected where the structural detail calls for a 440mm length with a 215mm width and 215mm height.

Quick spec

Length (L)	440mm
Width (W)	215mm
Height (H)	215mm

Why this size is specified

215mm width for details specifying a larger bearing area within the support geometry
440mm length for bearing details specifying this unit length
215mm height for deeper bearing build-ups shown on drawings/specification

What the dimensions control

Length (L) – bearing length available/required within the support detail
Width (W) – bearing area and compatibility with the support geometry
Height (H) – alignment with the specified bearing build-up and surrounding masonry

Note: Padstone dimensions should match the structural detail shown on drawings/specification.

Specification & compliance note

Padstones are selected to suit the project’s structural design and bearing detail. Always follow the structural drawings and specification.
In UK practice this sits under Building Regulations structural requirements (Approved Document A) and recognised masonry design principles
(commonly aligned with Eurocode 6 / BS EN 1996), with the project engineer’s detail taking precedence.

Available padstone sizes (quick links)

Size (L × W × H)	Product	Typical selection note
150 × 100 × 150mm	150 × 100 × 150mm Padstone	Compact bearing pad where drawings call for a smaller unit
215 × 100 × 140mm	215 × 100 × 140mm Padstone	Low-profile option where a 140mm height is specified
330 × 100 × 140mm	330 × 100 × 140mm Padstone	330mm length, 100mm wide, 140mm height
330 × 100 × 215mm	330 × 100 × 215mm Padstone	Same 330×100 footprint, taller 215mm height
440 × 100 × 140mm	440 × 100 × 140mm Padstone	440mm length, 100mm wide, 140mm height
440 × 100 × 215mm	440 × 100 × 215mm Padstone	440mm length, 100mm wide, 215mm height
440 × 140 × 215mm	440 × 140 × 215mm Padstone	440mm length, 140mm wide, 215mm height
440 × 215 × 215mm	440 × 215 × 215mm Padstone	440mm length, 215mm width, 215mm height
660 × 100 × 215mm	660 × 100 × 215mm Padstone	Often searched as “600mm padstone” (actual length 660mm)
900 × 100 × 215mm	900 × 100 × 215mm Padstone	Long bearing length where specified
L-shaped 440/440 × 100 × 215mm	L-shaped Corner Padstone	Corner/return bearing situations where an L unit is specified

View all padstones

Additional information

Weight	43 kg
Height	215mm
Length	440mm
Depth	215mm
Brand	FP McCann
